eSUN ePACF Filament στο 3DHUB!

eSUN ePACF filament is a robust filament developed based on Nylon 6/66 copolymer and enriched with 20% carbon fibre. It has increased strength, rigidity and toughness and can replace metal materials in many cases.

Its self-lubricating wear resistance makes the filament ideal for printing gears. In addition, the high toughness and impact resistance enable the production of durable parts that can withstand temperatures of up to 120 °C. The heat distortion temperature of eSUN ePA-CF is around 155℃.

The surface of the printed models is matt and fine.

Application of eSUN ePA-CF

• Mechanical engineering
• Automotive applications
• Electronics
• Aerospace

Recommended Extrusion/Nozzle Temperature 240°C – 260°C

Specifications:
Color: Natural
Material: Carbon Fiber
Filament Diameter: 1.75mm
Dimensional Accuracy: +/- 0.05mm
Extrusion Temp: 240 to 260 Celsius. Recommend 255 Celsius at least.
Build Plate Temp: 80 Celsius
Speed While Extruding: 30 to 60mm/s
Speed While Traveling: 90 to 150mm/s
Net Weight: 1kg/2.2lbs

Note:
Carbon-Fiber Filled materials are abrasive. Use all-metal hotend is required.
