BIGTREETECH Panda Touch V1.0 5-inch capacitive touchscreen

79,90 ME ΦΠΑ

Availability: In Stock
SKU: PANDATOUCH

Panda Touch is a responsive 5-inch capacitive touchscreen with intuitive controls that is compatible with Bambu Lab 3D printers from the X1, P1 and A1 series.

Features & Advantages

  • For Bambu Lab X1, P1 & A1 series
  • Responsive, with intuitive controls
  • 5-inch capacitive display
  • Wireless connection with WiFi
Credit module tbi bank 1.1.1

Panda Touch is a responsive 5-inch capacitive touchscreen with intuitive controls that is compatible with Bambu Lab 3D printers from the X1, P1 and A1 series.

IMPORTANT NOTE:
The Panda Touch is currently compatible with all Bambu Lab printer firmware versions up until:
– P1P –> v01.05.02.00
– P1S –> v01.05.02.00
– X1C –> v01.07.02.00
– A1 –> v01.01.01.00
– A1 Mini –> v01.01.03.00

It is possible that Bambu Lab may release a future firmware version which impacts the functions available from the Panda Touch. Bigtreetech will monitor all beta firmware versions and if we find a firmware version that affects Panda Touch functionality we will send out an alert via email, Aliexpress chat and our social channels. Buyers can then decide whether or not they would like to perform the update at the risk of losing functionality. Note that the Panda Touch warranty does not cover lost functionality due to a Bambu Lab firmware update being performed.

Click the link to view Panda Touch software instructions and more product information: https://bttwiki.com/PandaTouch.html


Product Description:

The Panda Touch is a 5” touchscreen developed by BIGTREE Technology Co., LTD., It offers a beautiful UI with convenient features and can be used as an alternative or a replacement screen for the Bambu P1P and Bambu P1S. It also interfaces with the X1 and A1 series and supports group printing and control for up to 10 Bambu Labs printers.

Key Features:

  • Plug-and-play convenience. Enjoy hassle-free setup with a quick installation that does not void your warranty.
  • Customized UX & UI. BTT delivers a tailored user experience that remains familiar but adds the extra features needed for multi machine control.
  • Versatile functionality. All of the functions you would expect from a rich graphical display, with some extras thrown in!
  • Seamless connectivity. Connect effortlessly via WiFi.
  • Magnetic charging. Effortless mobile portability with convenient magnetic charging technology.
  • Multi-printer control. Effortlessly manage multiple printers simultaneously for seamless synchronized control and printing.
  • AMS filament changing system control. Get easy access to the multi-color printing controls with one touch access to control over the filament-changing system.

5'' IPS Touch ScreenAMS Management

Characteristics:

► Plug and Play: Unpack the display and start your creative journey;

► Custom UX and UI system;

► Responsive for intuitive control;

► Power supply via a USB-C interface (special holder is included);

► Wireless connection with WiFi 2.4G for more flexibility and security; Printing from an SD card is supported;

► Simultaneous control of multiple 3D printers (management of up to 10 devices);

► Offline printing, monitoring and control functions;

► Uncomplicated AMS management and effective administration of AMS units;

► 30-minute battery life; Charging of the built-in lithium battery via a magnetic base with 5 magnets.


Included:

  • 1 x Panda Touch
  • 1 x Magnetic Charging Station
  • 1 x User Manual
  • 1 x Mounting Bracket
  • 1 x Packaging Box
  • 1 x M3x6 Flat Head Countersunk Head
  • 4 x screw (FHCS)
  • 1 x USB Charging Cable
  • 1 x Hex Key
  • 1 x BTT Duck

Technical specifications:

MCU Xtensa 32-bit LX7 dual-core ESP32S3R8, up to 240 MHz
Display size 5 inches
Display Full-view IPS with 16.7M colors
Operating temperatur 0-60°C
Logic voltage 3.3V
Recharge time 1.2 hours
Storage PSRAM-8MB, Flash-16MB
Resolution 800×480 pixels
Communication 2.4G WiFi (IEEE 802.11 b/g/n)
Operating voltage 5V 0.5A (max. 0.7A)
Battery up to 0.5 hours
Expansion interfaces I²C for temperature and humidity sensors, USB drive
